Axiom Vectric Photo Vcarve Software AVC100

What is PhotoVCarving?
PhotoVCarve instantly converts photographs and images into high-quality tool paths that can be run on virtually all CNC routing and engraving machines.

What can it do?
The ability to permanently CNC machine pictures onto jobs has been a challenge to many machine users. Although there are software products that appear to offer the facility, they often fail to deliver in reality.

PhotoVCarve is also perfect for machining 3D Lithophanes directly from photographs, which make perfect gifts, keepsakes, and souvenirs that will last for generations.

The opportunities PhotoVCarve offers are endless and it can be used by all CNC machine users. From the hobbyists who build their own ‘home brew’ tables to professional engravers running high-cost industrial machines, the software offers something for everyone.

Features:

• 1. V-Groove Machining
  PhotoVCarve creates lines of grooves that vary in width and depth to represent the detail in a photograph or image. The quality of the finished result is very dependent upon a high level of contrast between the material surface and the machined grooves. This information is very important to remember when cutting designs using the PhotoVCarve software.

  PhotoVCarve machines dark areas in a photograph with wide grooves and the lighter areas have narrower ones. The software automatically calculates the tool paths based on the cutter selected and the maximum depth of groove required.

  This diagram shows how the machined grooves get wider over the dark areas of the eye.



• 2. 3D Lithophane Machining
  Lithophanes are 3D photographs that when viewed in normal lighting look a little dull and lifeless. But when back lit transforms into stunning 3D pictures with depth and detail that cannot be seen in a flat 2D photograph.

  Lithophanes originate from a process developed back in the mid-1800s for mass-producing 3D pictures in porcelain. A 3D design was hand engraved into a thin sheet of beeswax that was placed over a lighted candle to show the effect of light passing through the wax. This master design was then used to make a mold for casting designs in porcelain. Varying levels of light pass through the porcelain depending on the thickness



• 3. 3D Grayscale Machining
  PhotoVCarve automatically converts a grayscale image into a 3D height map that can then be carved.
