• Description

The features you love on the 3520B Lathe are now available in a smaller footprint. The PM2020 Lathe is perfect for turners short on space, or projects where a short bed is convenient. Like its big brother, the PM2020 features a sliding headstock, electronic variable speed with low and high speed ranges, and the spindle lock. The enhanced features include a digital RPM readout, built in spindle indexing on the head stock, and a re-designed tailstock with internal storage, chrome trimmed handwheels, and a laser etched quill which is self-ejecting. Additional features include a two position mount for the optional bed extension, a sliding hammer knockout rod with brass tip, an attached tool caddy and a metal shelf for tool storage.

Features
  • Brass-tipped knockout bar concentrates the action in the sliding handle; the brass tip will not damage drive centers
  • Digital RPM readout for accurate speed adjustments
  • Redesigned tool rest geometry allows for better chisel movement along the tool rest
  • Set of dead centers which hold a spindle for visual comparison
  • Sliding headstock with electronic variable speed
  • Spindle lock and built in spindle indexing on the headstock for drilling hole patterns, routing flutes and other equally spaced features
  • Tailstock has internal storage for additional accessories
  • Tailstock has internal storage for additional accessories and attached tool caddy allows convenient access to centers and wrenches
  • Two position mount for optional bed extension
  • IMPORTANT: This Lathe cannot be run on a GFCI circuit. Please reference the manual for more information. When Lathe is not in use, disconnect from power.

Specifications

Stock Number PM9-1792020
Bed Construction Cast Iron
Distance Between Centers (In.) 20
Gross Weight (Lbs) 609
Model Number PM2020
Motor Amps 6.2
Motor (HP) 2.0
Motor Power (HP) 2
Motor Voltage (V.) 220
Net Weight (Lbs.) 559
Prop 65 Cancer and Reproductive Harm
Recommended Circuit Size (Amps.) 20
Shipping Dimensions (L x W x H) (In.) 55-1/8 x 27-1/4 x 30-5/8
Swing Over Bed (In.) 20
Weight (Lbs.) 559
